Frame
Alpha Gold Aluminium, DuoTrap S-compatible, internal cable routing, flat-mount disc, rack and mudguard mounts, 135x5 mm QR
Fork
FX Alloy, flat-mount disc, rack mounts, 405 mm axle-to-crown, ThruSkew 5 mm QR
Hub front
Formula DC-20, alloy, 6-bolt, 5x100 mm QR
Hub rear
Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR
Rim
Bontrager Connection, alloy, double-wall, 32-hole, Schrader valve
Tyre
Size: S/M/L/XL, Bontrager H2 Hard-Case Light, 700x35c
Size: S/M/L/XL, Bontrager H2 Comp, wire bead, 30 tpi, 700x32c
Max tyre size
38c without fenders, 35c with fenders
Shifter
Shimano Altus M2010, 9-speed
Front derailleur
Shimano Acera T3000, 34.9 mm clamp, top swing, dual pull
Rear derailleur
Shimano Altus M2000, long cage
Crank
Forged alloy, 46/30, chainguard, 170 mm length
Cassette
Shimano HG200, 11-36, 9-speed
Chain
KMC X9
Pedal
Size: S/M/L/XL, Bontrager City pedals
Size: S/M/L/XL, Wellgo C157, boron axle, plastic body
Saddle
Bontrager Sport
Seatpost
Bontrager alloy, 27.2 mm, 12 mm offset, 330 mm length
Handlebar
Size: S/M, Bontrager alloy, 31.8 mm, 15 mm rise, 600 mm width
Size: L/XL, Bontrager alloy, 31.8 mm, 15 mm rise, 660 mm width
Grips
Bontrager Satellite
Stem
Size: S/M, Bontrager alloy, 31.8 mm clamp, Blendr-compatible, 7-degree, 90 mm length
Size: L/XL, Bontrager alloy, 31.8 mm clamp, Blendr-compatible, 7-degree, 100 mm length
Head set
1-1/8" threadless, sealed cartridge bearings
Brake
Size: S/M/L/XL, Tektro HD-R280 hydraulic disc, flat mount, 160mm rotorSize: S/M/L/XL, Tektro HD-R280 hydraulic disc, flat-mount, 160 mm rotor
Light
Size: S/M/L/XL, Spanninga SOLO
Size: S/M/L/XL, AXA Greenline 35, USB rechargeable
Kickstand
Alloy, rear-mount kickstand
Cargo rack
Alloy rear rack
Mudguard
Eurofender Snello
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
