The Fuel EX 5 is a full-suspension trail bike that's ready to handle it all.
The Fuel EX 5 is a full-suspension trail bike that's ready to handle it all.
Trek

Trek Fuel EX 5 Mountain Bike in Black

£2,325.00
Size Guide
Earn
in Customer Rewards when you buy this item today
Sign Up
Sign In
Pre-Order

With Pre-Order, you can purchase the latest items added to our store in advance of them arriving with us.

Your Pre-Order is prioritised (at no additional charge); meaning that as soon as the product arrives with us, we can wrap it straight back up; ready for collection via Click & Collect or despatch to you — it often never even hits the stock room shelves!

Pre-Launch

With Pre-Launch, the date when we expect to receive the product ourselves is still a little too hazy to be confident in accepting Pre-Orders.

So, instead, you can submit your email address against the item you are interested in and we will email you as soon as stock arrives on the system.

Estimated Delivery & Collection Dates

Estimated Delivery & Collection Dates are given on Pre-Order and Pre-Launch products. They are for indication purposes only and can change at any time without notice.

The dates we provide are based on indications given by our suppliers. Whenever we get updated information from our suppliers we will endeavour to update the Estimated Delivery & Collection Dates provided on product pages.

We estimate this will be ready for despatch to you or collection via Click & Collect on Undetermined
Earn Rewards
When you purchase this item, you will earn of rewards points to spend on your next purchase from us. You can spend your Rewards balance in-store & online.

Trek Fuel EX 5 Mountain Bike in Black

Season:2023

Brand:Trek

Code:33073BLK

The Fuel EX 5 is a full-suspension trail bike that's ready to handle it all.

With trail-taming 140 mm front and 130 mm rear suspension, a Shimano 1x12 drivetrain, a dropper post for getting low on descents and hydraulic disc brakes, the Fuel EX 5 hits the mark as a high-value, high-performance mountain bike with exceptional versatility.
Technical Information
  • Frame
    Alpha Platinum Aluminium, tapered head tube, Knock Block, Control Freak internal routing, downtube guard, ISCG 05, magnesium rocker link, Mino Link, ABP, Boost148, 130 mm travel
  • Fork
  • Size: XS , S
    RockShox Recon Silver, DebonAir spring, Motion Control damper, lockout, tapered steerer, 46 mm offset, Boost110, Maxle Stealth, 140 mm travel
  • Size: S , M , ML , L , XL , XXL
    RockShox Recon Silver, DebonAir spring, Motion Control damper, lockout, tapered steerer, 42 mm offset, Boost110, Maxle Stealth, 140 mm travel
  • Shock
  • Size: XS , S
    X-Fusion Pro 2, 2-position damper, 210 mm x 52.5 mm
  • Size: S , M , ML , L , XL , XXL
    X-Fusion Pro 2, 2-position damper, 210 mm x 55 mm
  • Max compatible fork travel
    150mm (561mm axle-to-crown)
  • Hub front
    Bontrager alloy, 6-bolt, Boost110, 15 mm thru-axle
  • Hub rear
    Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Shimano MicroSpline freehub, Boost148, 12 mm thru axle
  • Skewer rear
    Bontrager Switch thru-axle, removable lever
  • Rim
    Alex MD35, tubeless compatible, 32-hole, 35 mm width, Presta valve
  • Tyre
  • Size: XS , S
    Bontrager XR4 Comp, wire bead, 30 tpi, 27.5x2.60"
  • Size: S , M , ML , L , XL , XXL
    Maxxis Rekon EXO, wire bead, 60 tpi, 29x2.60''
  • Size: S , M , ML , L , XL , XXL
    Bontrager XR4 Comp, wire bead, 30 tpi, 29x2.60"
  • Rim strip
    Bontrager TLR
  • Max tyre size
    Frame: 29x2.60" Fork: See manufacturer
  • Drivetrain
    Shifter
  • Rear derailleur
    Shimano Deore M6100, long cage
  • Crank
  • Size: XS , S , M , ML , L
    Shimano MT511, 30T steel ring, 52 mm chainline, 170 mm length
  • Size: M , ML , L , XL , XXL
  • Shimano MT511, 30T steel ring, 52 mm chainline, 175 mm length
  • Bottom bracket
    Shimano MT500, 92 mm, PressFit
  • Cassette
    Shimano Deore M6100, 10-51, 12-speed
  • Chain
    Shimano Deore M6100, 12-speed
  • Max. chainring size
    34T
  • Saddle
    Bontrager Arvada, steel rails, 138 mm width
  • Seatpost
  • Size: XS , S
    TranzX JD-YSP18, 100 mm travel, internal routing, 31.6 mm, 361 mm length
  • Size: M , ML , L , XL , XXL
    TranzX JD-YSP18, 130mm travel, internal routing, 31.6 mm, 425 mm length
  • Handlebar
    Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width
  • Grips
    Bontrager XR Trail Comp, nylon lock-on
  • Stem
    Bontrager Rhythm Comp, 31.8 mm, Knock Block, 0-degree, 50 mm length
  • Head set
    Knock Block Integrated, 58-degree radius, cartridge bearing, 1-1/8" top, 1.5" bottom
  • Brake
    Shimano hydraulic disc, MT201 lever, MT200 calliper
  • Brake rotor
    Shimano RT56, 6-bolt, 180 mm
