Frame
OCLV Mountain Carbon, internal storage, tapered head tube, Knock Block 2.0, internal guided routing, downtube guard, magnesium rocker link, Mino Link, ABP, Boost148, 120 mm travel
Fork
RockShox Pike Select+, DebonAir spring, Charger 3 RC2 damper, tapered steerer, 44mm offset, Boost110, 15mm Maxle Stealth, 130mm travel
Shock
RockShox Deluxe Ultimate RCT, 185 mm x 50 mm
Max compatible fork travel
130mm (541mm axle-to-crown)
Wheel front
Bontrager Line Elite 30, OCLV Mountain Carbon, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle
Wheel rear
Bontrager Line Elite 30, OCLV Mountain Carbon, Tubeless-Ready, Rapid Drive 108, 6-bolt, Shimano MicroSpline freehub, Boost148, 12 mm thru axle
Hub front
Bontrager alloy, sealed bearing, alloy axle, 6-bolt, Boost110, 15 mm thru axle
Skewer rear
Bontrager Switch thru-axle, removable lever
Tyre
Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120 tpi, 29 x 2.40''
Tyre part
Bontrager TLR sealant, 180 ml/6 oz
Max tyre size
Frame: 29x2.50", Fork: See manufacturer
Shifter
Shimano XT M8100, 12-speed
Rear derailleur
Shimano XT M8100, long cage
Crank
Size:S, M, M/L, L
Shimano XT M8120, 30T, 55mm chain line, 170mm length
Size:XL
Shimano XT M8120, 30T, 55mm chain line, 175 mm length
Bottom bracket
Shimano BB-MT501 BSA
Cassette
Shimano XT M8100, 10-51, 12-speed
Chain
Shimano Ultegra/XT M8100, 12-speed
Max. chainring size
1x: 36T round, 34T oval, min 28T
Saddle
Bontrager Arvada, austenite rails, 138 mm width
Seatpost
Size:S
Bontrager Line Elite Dropper, 100mm travel, MaxFlow, internal routing, 34.9mm, 345mm length
Size:M, M/L
Bontrager Line Elite Dropper, 150 mm travel, MaxFlow, internal routing, 34.9 mm, 440 mm length
Size:L
Bontrager Line Elite Dropper, 170 mm travel, MaxFlow, internal routing, 34.9mm, 485 mm length
Size:XL
Bontrager Line Elite Dropper, 200 mm travel, MaxFlow, internal routing, 34.9mm, 550 mm length
Handlebar
Size:S
Bontrager Line Pro, OCLV Carbon, 35 mm, 15 mm rise, 750 mm width
Size:M, M/L, L, XL
Bontrager Line Pro, OCLV Carbon, 35 mm, 27.5 mm rise, 780 mm width
Grips
Bontrager XR Trail Elite, nylon lock-on
Stem
Bontrager Line Pro, 35 mm, Knock Block, Blendr-compatible, 0-degree, 45 mm length
Head set
Knock Block 2.0 Integrated, 72-degree radius (includes infinite-radius chip), sealed cartridge bearing, 1-1/8" top, 1.5" bottom
Brake
Shimano XT M8120 4-piston hydraulic disc
Brake rotor
Size:S, M, M/L, L, XL
Shimano RT76, 6-bolt, 160 mm
Size:S, M, M/L, L, XL
Shimano RT76, 6-bolt, 180 mm
Rotor size
Max brake rotor sizes: Front see fork manufacturer, rear 180 mm
